WorxAudio W-8A | High Efficiency Passive Loudspeaker

产品简介

The W-8A is a two-way, high efficiency, passive loudspeaker. It is designed as a compact high performance system for the reproduction of speech and music program material.

Clear and Present

The W-8A is a two-way, high efficiency, passive loudspeaker. It is designed as a compact high performance system for the reproduction of speech and music program material.

The W-8A has a 1-inch exit compression driver coupled to a 75 x 75-degree wooden waveguide horn for reproducing high frequencies and an 8-inch cone transducer in a tuned enclosure for the low frequencies. A high-quality passive network operates very efficiently, also providing EQ points for a flat frequency response.


Built to Last

The W-8A's sturdy multi-ply plywood enclosure and multi-layered catalyzed Polyurea finish is designed to withstand the most demanding applications. A perforated, powder-coated steel grille with a high transmission ratio offers excellent protective properties.

The W-8A can be purchased in two versions. The install (W-8Ai) configuration has a passive internal crossover, while the W-8Ai-P is self-powered. Both models have a standard 12-point flyware system. Both are available in white, black, or unfinished exterior.



技术指标

Key features

  • Ultra Compact

  • Acoustic Waveguide

  • Integrated Rigging System

  • Flat Phase & Power Response

  • Durable Catalyzed Multi-layered Finish

  • High Quality Optimized Passive Crossover


Technical Specifications

System Performance

Frequency Response (-3 dB) *           68 Hz – 17 kHz

Frequency Range (-10 dB)           48 Hz – 19 kHz

Recommended           High-Pass 40 Hz – with minimum 24 dB / octave (4th order) Butterworth slope

Nominal directivity (-6 dB)          Horizontal: 75°

Nominal directivity (-6 dB)           Vertical: 75°

Recommended Crossover Frequency           1.6 kHz (acoustic, active, external DSP)

RMS handling capacity **

  • LF: 150W

  • HF: 60W

Maximum SPL @ 1 Meter ***           121 dB ([WorxAudio] preset)

Transducers

Components

  • LF: 8” (203.2 mm) x 1

  • HF: 1” Exit (25.4 mm) x 1

Nominal Impedance           LF = 8 ohms, HF = 8 ohms, Self Powered Passive: 8 ohms

Physical

Enclosure           Baltic birch plywood, engineered plastics, and aluminum frame

Finish           Two-part spray catalyzed Polyurea coating on plywood

Grille           16-gauge (0.06 mm) perforated steel, powder-coated finish, black

Environmental           Indoor use only

Connectors           Passive Version: Two (2) parallel-wired NL4 Neutrik® Speakon® connectors

Power Amp Connectors           Self Powered Version: Neutrik® PowerCon (AC) XLR M/F (In/Out) or Dante

Suspension/Mounting           Internal bracket w/ threaded 0.375” flying points (x12)

Dimensions           18.25” H x 11.25” W x 12” D (463.55 mm x 317.5 mm x 285.75 mm)

Net Weight           34 lb. (15.42 kg)

Shipping Weight           39 lb. (17.69 kg) - approximate with carton

Product Versions           W-8Ai: Passive; W-8Ai-P: Powered

Digital Power Amp

  • 1000W driving passive 8 ohm

  • Digital program processing

  • XLR I/O Dante-enabled

  • AC powerCON I/O


Footnotes

* Frequency response and range measured on-axis with anechoic environment.

** Power handling tested using pink noise filtered to meet IEC 268-5, 6 dB crest factor, 100 hours, with recommended EQ.

*** Peak level measured at 1m under free field conditions using 10 dB crest factor pink noise with specified ([WorxAudio] preset) and corresponding EQ settings.
